PGM-IR Portable Refrigerant Monitor
เครื่องเช็ครั่วก๊าซแบบพกพา

Type			        Portable Gas Monitor using infrared NDIR sensor

Gases			        Refrigerants: CFCs, HFCs, HCFCs, HFOs
                                Natural Refrigerant: CO2
                                Medicine and Propellant: N2O
                                Inert Gas: SF6

Measuring Range	        Refrigerants: 0 to 10,000 ppm
                                CO2: 0 to 8,000 ppm
                                N2O, SF6: 0 to 1,000 ppm

Sensitivity		        1 ppm

Flow Rate		        1 L/min (typical)

Response Time	        t90 ≤ 5 s

Display			Backlit graphic LCD; audible ticker

Battery			Rechargeable Li-Ion, 8 hours of continuous operating time

Ambient Conditions	Temperature: 32 to +122 °F (0 to +50 °C)
                                Humidity: 5 to 90 %RH, non condensing
                                Altitude: 0 to 6,560 ft (2,000 m)

Enclosure		        Powder coated aluminum in soft case with shoulder strap

Size (w x h x d)	        Approx. 19” x 5” x 8” (500 x 130 x 200 mm)

Weight			Approx. 7 lbs. (3.2 kg)

Approvals		        CE mark; NOT approved for use in classified, hazardous areas
